600GF-Z Biogas genenrator
1、High intelligence
2、Low warmness consumption
3、high reliability
4、High energy technology effectivity
Biogas power generation technology is a new energy comprehensive utilization technology that integrates environmental protection and energy conservation. It utilizes a large amount of organic waste from industry, agriculture, or urban life (such as distiller's grains, livestock manure, urban garbage, and sewage), and produces biogas through anaerobic fermentation treatment. It drives the biogas generator set to generate electricity, and can fully utilize the waste heat of the generator set for biogas production.
Model | 600GF-Z |
Alternator model | 1FCseries,siemens technology.Brushless excitation,Automatic voltage regulation. |
Panel model | GPL600 |
Rated power | 600kW |
Rated voltage | 400V/480V/6300V/10500/13800 |
Rated frequency | 50/60HZ |
Rated power factor | 0.8 |
Wiring mood | 3 Phase 4 Wire/3 Phase 3 Wire |
Production class | IP23 |
Insulation class | H |
Stabilized voltage regulation | ±2.5% |
Transient state voltage regulation | +20%（-15） |
Voltage stabilization time | ≤1.5s |
Fluctuation rate of voltage | ≤1% |
Stabilized frequency regulation | 0~5% |
Transient state frequency regulation | ≤±10% |
Frequency stabilized time rate | ≤7s |
Fluctuation rate of frequency | ≤0.5% |
Overall dimension | 5120mm*2040mm*2776.5mm |
Net weight | 13800kg |
Engine model | G12V190ZLZ-2 |
Type | Four strokes,Vshape，turbocharged intercooling，spark plug ignition. |
Number of cyliner | 12 |
Bore | 190mm |
Stoke | 210mm |
Total displacement | 71.5L |
Rated speed | 1000r/min |
Rated power | 550KW |
Idle speed | 700r/min |
Gas pressure | 10-40KPa |
Gas consumption | ≤11000kJ/kW·h |
Oil consumption | ≤0.8g/kW·h |
Exhaust tem.(before turbine） | ≤650℃ |
Water oulet temperature | ≤85℃ |
Water inlet temperature of intercooler | <45℃ |
Oil temperature | <90℃ |
Stabilized speed droop | 0~5% |
Cooling mood | Open type-cooling tower/closed type-vertical or horizontal radiator |
Lubrication method | Pressure and splash lubrication |
Starting mood | Electric starting |
Crankshaft rotation | Counter-clockwise（face to flywheel） |
After Sale Service
1. Provide container design and power distribution design for customers
2. Install and debug generator sets for customers and provide guidance
3. Provide technical training and consultation
4. Having sufficient spare parts for the gas generator set
5. Provide technical assistance
Packing&Delivery
1) Gas engine generator would be included with plywood bins
2) Control panel, batteries, electric powered cables are packed with plywood containers or cartons
3) Exhaust pipes, engine mufflers are put in the container except packing.
