750kVA Biogas Engine Generator

Excessive quality, lengthy utilization life, handy operation Low renovation cost, excessive Genius with low engine speed Low gas consumption, low fuel exceptional requirement

Hard environmental adaptability, excessive balance and low fluctuation

  Contact Now
Product Details

Biogas combustion energy technology is a biogas utilization science that has emerged with the non-stop improvement of large-scale biogas digesters and complete utilization of biogas. It makes use of the biogas generated through anaerobic fermentation remedy on the engine and is geared up with a complete electricity era gadget to generate electrical energy and warmth energy. Biogas energy technology has the traits of effectivity creation, power conservation, safety, and environmental protection, and is a broadly disbursed and in your price range disbursed electricity source.

Genset model

600GF-Z

Alternator model

1FCseries,siemens technology.Brushless excitation,Automatic voltage regulation.

Panel model

GPL600

Rated power

600KW

Rated voltage

400V/480V/6300V/10500/13800

Rated frequency

50/60HZ

Rated power factor

0.8

Wiring mood

3 Phase 4 Wire/3 Phase 3 Wire

Production class

IP23

Insulation class

H

Stabilized voltage regulation

±2.5%

Transient state voltage regulation

+20%-15

Voltage stabilization time

≤1.5s

Fluctuation rate of voltage

≤1%

Stabilized frequency regulation

0~5%

Transient state frequency regulation

≤±10%

Frequency stabilized time rate

≤7s

Fluctuation rate of frequency

≤0.5%

Overall dimension

5120mm*2040mm*2776.5mm

Net weight

13800kg



Engine model

G12V190ZLZ-2

Type

Four strokes,Vshapeturbocharged intercoolingspark plug ignition.

Number of cyliner

12

Bore

190mm

Stoke

210mm

Total displacement

71.5L

Rated speed

1000r/min

Rated power

550KW

Idle speed

700r/min

Gas pressure

10-40KPa

Gas consumption

≤11000kJ/kW·h

Oil consumption

≤0.8g/kW·h

Exhaust tem.(before turbine

≤650℃

Water oulet temperature

≤85℃

Water inlet temperature of intercooler

<45℃

Oil temperature

<90℃

Stabilized speed droop

0~5%

Cooling mood

Open type-cooling tower/closed type-vertical or horizontal radiator

Lubrication method

Pressure and splash lubrication

Starting mood

Electric starting

Crankshaft rotation

Counter-clockwiseface to flywheel


750kVA Biogas Engine Generator

750kVA Biogas Engine Generator

After Sale Service

1. Provide container layout and electricity distribution design
2. Provide education for set up and debugging
3. Provide technical coaching and session for users' operation and preservation personnel
4. Guide maintenance
5. Establish purchaser profiles for give up customers and song services
6. The corporation presents spare parts, and upkeep engineers furnish technical help at any time

After Sale Service


Packing&Delivery

We commonly undertake transport through bulk cargo, container, packing Standard export packing, or custom-made packing as your request. We will organize the most inexpensive transportation mode in accordance to the extent of products. All merchandise have long past thru strict inspection and are in true situation earlier than shipment. We attempt for one hundred percent consumer pleasure on each and every sale we close.

Packing&Delivery

Production line

Production line

Exhibition

Exhibition
